R928017460(10.60 LA H10XL-000-6-M SO3000) Replacement Filter

Prev: HX-25x10Q Leemin Pipeline Press Oil Filter Element Next: TXW12CC10/R742G10 Parker/Filtrec Replacement
R928017460(10.60 LA H10XL-000-6-M SO3000) Replacement Filter

Brand:PartnerFilter

Model: R928017460

Type: Hydraulic Oil Filter Cartridge

Seal: Buna (Nitrile)

Bypass Setting: 43psid

Collapse: 250psid

Filter material: Fiberglass

Sizes: OD1.877”*L3.91”

End Caps: Corrosion Resistant Steel

Center Tube: Corrosion Resistant Steel

R928017460 hydraulic oil filter is equal to 10.60 LA H10XL-000-6-M SO3000the replacement filter of Bosch Rexroth is produced by PartnerFilter with high quality fiberglass material.It plays an extremely important role in cleaning oil of all kinds of machinery and ensuring its smooth operation.
  About Us       Contact Us Product Details       Related Specification Filters       Communication Requirements

Brief Introduction:

R928017460 is a hydraulic oil filter element,and it’s an indispensable part of the pipeline series for conveying media.It is usually installed in the inlet filter of the hydraulic system to filter out metal particles and pollutants in the fluid medium to protect the normal operation of mechanical equipment.

The R928017460 hydraulic oil filter elements application range is very wide,covering almost all industries:

iron and steel,electric power,metallurgy,shipbuilding,aviation,papermaking,chemical industry,machine tools and construction machinery,engineering machinery and other fields.


Test standards:

ISO 2941 Collapse & Burst Resistant

ISO 2942 Fabrication & Integrity Test

ISO 2943 Material Compatibility with Fluids

ISO 3724 Flow Fatigue Characteristics

ISO 3968 Pressure Drop vs. Flow Rate

ISO 16889 Multi-pass Performance Testing


More Bosch Rexroth & Hydac Filter Interchange:

MNRMODELEqual Hydac
R92801743710.30 LA H10XL-000-6-M So30000030R010BN4HC
R92801746010.60 LA H10XL-000-6-M SO30000060R010BN4HC
R92801903710.75 LA H10XL-000-6-M So30000075R010BN4HC
R92801748310.110 LA H10XL-000-6-M So30000110R010BN4HC
R92801750610.160 LA H10XL-000-6-M SO30000160R010BN4HC
R92801903510.165 LA H10XL-000-6-M SO30000165R010BN4HC
R92801752910.240 LA H10XL-000-6-M So30000240R010BN4HC
R92801755210.330 LA H10XL-000-6-M SO30000330R010BN4HC
R92801764410.660 LA H10XL-000-6-M SO30000950R003BN4HC
R92801766710.950 LA H10XL-000-6-M SO30001300R010BN4HC
R92801707510.1300 LA H10XL-000-6-M SO30000030D005BN4HC
R9280171119.30 LA H6XL-A00-O-M SO30000060D010BN4HC
R9280171129.6O LA H10XL-AO0-O-M SO30000060D005BN4HC
R9280171449.60 LA H6XL-A00-O-M So30000110D010BN4HC
R9280171459.110 LA H10XL-AO0-O-M SO30000110D005BN4HC
R9280172119.110 LA H6XL-A00-O-M SO30000160D005BN4HC
R9280173099.160 LA H6XL-A0O-O-M SO30000330D010BN4HC
R9280171119.60LA H10XL-A00-0-M SO30000060D010BN4HC
R92801757510.500LA PWR-A00-6-M0500R010BN4HC
12608960280 D 005 BN4HC0280D005BN4HC
12629450110 R 010 ON0110 R 010 ON
12528930300 RK 010 MM0300R010BN4HC
R9280068092.0160 H10XL-A00-0-M0630RN025BN4HC
12608880500 D 020 ON0500 D 020 ON
2490050160 MG 010 P0160 MG 010 P
R9280172439.240 H10XL-A00-0-M0240D010BN4HC
12609090660 D 003 BN4HC0660D003BN4HC
12531010500 D 020 BH4HC0500D020BH4HC
12504910240 D 010 ON0240 D 010 ON
R9280067640100 DN 010 BH4HC0100DN010BH4HC
3011930500 D 100 W0500 D 100 W
3140220160 MA 010BN0160 MA 010BN
3156230180 MA 020BN0180 MA 020BN
R9280067642.0100 H10XL-B00-0-M0100DN010BNHC
12530980500 D 010 BH4HC0500D010BH4HC
R92802253718.519C H3XL-S00-0-M1000RN010BN4HC
R90260300462.0180K H20XL-J00-0-V


PartnerFilter also offers a full range of replacement filter elements.

They meet quality requirements and can be installed in the following products:

ARGO

DONALDSON

EPPENSTEINER

FILTREC

HYDAC

HY-PRO

INTERNORMEN

LEMMIN

MANN

MAHLE

MP-FILTRI

PALL

PARKER

REXORTH

STAUFF

TAISEI KOGYO

VICKERS

Other types are available on request



Related Specification Filters
Item Specifications
Top OD 1.877"
Bottom OD 1.877"
ID 0.874"
Height 3.91"
End Caps Material Corrosion Resistant Steel
Center Tube Material Corrosion Resistant Steel
Filter Media Micro fiberglass
Gasket Buna(Nitrile)
Collapse Rating 250 psid
Filtration Rating Bx = 200 Bx[c] = 1000

   Application Scenarios Of Filter Element

Air Compressor Filtration

Thermal energy power generation industry. Preventing and Controlling Clean Gas Emissions. Air Compressor Filter.

Reduce the emission of air pollutants, reduce the harm of air pollution to human healthy.

Equipment Oil Pollution Filtration

Large machinery production operation industry.Mechanical production operation equipment oil cleaning and filtration.

Highly efficient cleaning and filtering of oil dirt, protecting engine parts and other equipment.

Industrial Wastewater Filtration

Production wastewater treatment and cleaning. Avoid water pollution. Ensure healthy drinking water.

Ensure healthy drinking water.Avoid water pollution. Production wastewater treatment.

Oil Dust Filtration

Mineral development equipment filtration guarantee.Ensure the stability of mining operation machinery. Safety. Efficient.

Reduce the discharge of dust into the atmosphere. Ensure atmosphere standards.
